ix MIC-770 V3 User Manual
Optional Accessories
* Please refer to the Flex I/O datasheet for more details.
** AIIS-DIO32 requires a DB37 bracket (P/N: 1960068787N002)
*** R680E SKU only
Part Number Description
96PSA-A230W24P4-3 ADP A/D 100-240V 230W 24V C14 terminal block 4P
1702002600 Power cord (USA) UL/CSA, 3-pin, 10A, 125V, 1.83M, 180D
1700008921 Power cord PSE 3P 7A 125V 183cm
1702002605 Power cord (EU), 3-pin, 10A, 250V 1.83m, 90D
96PSD-A240W24-MN* A/D 100-240V 240W 24V NDR DIN-rail
1700031170-01 DC-DC power cord, A cable TEM*4/TEM*4 UL2464 18AWG 150 cm
1700029720-01 AC-DC power cord (US), M cable AC CONN 3P 183 cm
1700030520-01 AC-DC power cord (CN), M cable conn 3P CCC 10A 250V 150 cm
1700031408-01 AC-DC power cord (EU), M cable conn 3P/G-TEM*3 80 cm
AIIS-DIO32-00A1E** AIIS GPIO module (32-bit)
PCA-TPMSPI-00A1 TPM 2.0 module (SPI)
98R17500001 MIC DVI FIO
98R17500101 MIC HDMI/Remote power on/off FIO
98R17500301 MIC HDMI kit FIO
98R17500401 MIC Remote power on/off FIO
98R17500601 MIC COMport kit FIO
98R17500701 MIC remote power on/off kit for SFIO
98R17500802
MIC reset/remote power on/off/5V
DC
kit FIO
98R17500901 MIC GPIO kit
98R17501001 MIC DisplayPort kit
98R17501101 MIC COM and HDMI kit
98910770301*** MIC NVMe + 4 LAN Advanced FIO
98910770401*** MIC NVMe Advanced FIO
98910770501*** MIC 4 PoE Advanced FIO
98R1752010E 2nd 2.5" HDD/SSD kit (used in 2-slot i-Module)
98R1752020E MIC Dual SSD kit
98R17500201 MIC DIN-rail mounting kit (90/180)
98R17500210 MIC DIN-rail mounting kit (180)
98R17500501 MIC wall mounting kit
i-Door Module
(MOS series module)
Supports i-Door module (MOS series), except PoE.
Please refer to the Advantech website below or search "iDoor Mod-
ule Mini PCIe Expansion Kit”.
http://www.advantech.com.tw/products/idoor-module-mini-pcie-
expansion-kit/sub_bc858a7f-a52b-441b-a59c-f511289f98bc
i-Door Module
(PCM series module)
Supports i-Door module (PCM series), except PoE.
Please refer to the Advantech website below:
http://www.advantech.com/products/idoor-technology-mini-pcieex-
pansion-kit/sub_efdb96af-a8f7-4cde-9592-dbf5c9794d16
Note: A bracket is required to mount the PCM series i-door module.
Please refer to P/N: 1960065854N001 i Door_bracket
