3 MIC-7700 User Manual
Chapter 1 General Introduction
1.2.3 Ethernet
Chipset:
– Q170 LAN1: Intel® I219LM, LAN2: Intel® i210IT
– H110 LAN1: Intel® I219V, LAN2: Intel® i210IT
Speed: 10/100/1000 Mbps
Interface: 2 x RJ45
Standard: Compliant with IEEE 802.3, IEEE802.3u, IEEE 802.ab.
1.3 Chipset
1.3.1 Functional specification
1.3.1.1 Processor
1.3.1.2 Chipset
Processor Intel® 6th/7th Gen Core™ i CPU socket (LGA1151)
PCH Intel® Q170/H110 chipset
Memory
Supports DDR4 2133/2400MHz (without ECC)
SODIMM Socket:
– 260-pin SODIMM socket*2 (up to 16 GB per socket)
Chipset
integrated Intel
HD Graphic
Intel® HD Graphics 530/510
Supports DirectX 12
Supports OpenGL 4.4
Supports Intel® Quick Sync Video
IO interface
– VGA: Supports resolutions up to 2048 x 1152 @ 60 Hz
(VGA connector: On-board D-SUB 15P)
– DVI: Supports resolution up to 1920 x 1080 @ 60 Hz
(DVI Connector: On-board DVI-D 24P)
SATA Interface
3 x SATA3.0 (Q SKU), 1 x SATA3.0 (H SKU)
Legacy IED (Including IRQ)/Native AHCI appearance to OS
Partial/slumber power management modes with wake
Capable of 6Gbit/s transfer rate
USB Interface
Q170: 8 x USB 3.0 and 1 x internal USB 2.0
H110: 4 x USB 3.0 and 4 x USB 2.0
Supports high-speed, full-speed, and low-speed capable
Supports legacy keyboard/mouse software
Power
Management
Supports ACPI 5.0
ACPI Power Management Logic supported
Power Connector: plug-in block 4Px1
BIOS AMI 16Mb Flash BIOS via SPI
