MIC-717OX User Manual/用户手册 12
2.2.5 4In/4Out DI/DO
The MIC-717OX comes with a 4In/4Out DI/DO port on the rear side of the device.
MIC-717OX 在本机的后方提供了一组支持 4-bit 输入 /4-bit 输出的 DI/DO。
MIC-717OX 在本機的後方提供了一組支援 4-bit 輸入 /4-bit 輸出的 DI/DO。
Figure 2.7 DIO
Figure 2.8 DIO Pinout
Table 2.3: Isolated Digital Inputs
Number of Input Channels 4
Operative range level high 5 to 30 V
Input Voltage Max Input Voltage: 30V (minimum)
Max input current 5 to 30 V
Table 2.4: Isolated Digital Outputs
Number of Input Channels 4
Voltage Dry Contact Max Operating Voltage 30V
Current Dry Contact Max Operating Current 0.5A
