3 MIC-713 User Manual
Chapter 1 General Introduction
1.2.1.3 Peripheral & I/O
1 x HDMI 2.0 video output (Max. resolution 3840x2160 @ 60Hz)
6 x USB 3.2 Gen 2 (External)
1 x USB 2.0 (Internal, Micro USB connector for OTG)
1 x 4 ch-DI & 1 x 4 ch-DO
2 x RS-232/RS-422/RS-485 (Internal pin header reserved)
1 x Mini PCIe (PCIe x1+USB)
1 x iDoor space
1 x M.2 2280 NVMe slot (signal:PCIe x1)
1 x M.2 3052 slot (signal: USB)
1 x Micro SD
2 x NANO SIM (for mini PCIe & M.2 3052)
1.3 Mechanical Specifications
Standard SKU dimension: 194.8 x 174.3 x 65.85 mm (7.67" x 6.86" x 2.59")
Reference Weight: 2.05 kg (w/o packing material)
1.4 Electrical Specifications
Power type: AT/ATX
Power input: 9-36 V
DC
; 15-5.6 A
1.5 Environmental Specifications
Operating temperature: -10 ~ 60°C (14 ~ 140°F)*
Operating humidity: 95% @ 40°C (non-condensing)
Storage temperature: -40 ~ 85°C (-40 ~ 185°F)
Storage humidity: 60°C @ 95% RH non-condensing
194.80
65.85
