MIC-3332 User Manual 2
1.1 Introduction
MIC-3332 series are 3U CompactPCI single board computers with 6th Gen Intel
®
Quad Core™ i7/Xeon
®
E3 processors and CM236 chipset. It supports single-channel
memory with ECC optional, up to 16 GB on board DDR4 of 2133MHz speed. There
are various types of storage on the XTM board: including a 2.5" SATA connector, a
Cfast socket, and an additional Micro-SD slot on the XTM-2 board. MIC-3332 is avail-
able in single and dual slot width form factors, to offer various I/O functionality by
XTM(8HP) and rear I/O extensions. Front panel I/O on the single slot (4HP) provides
1x VGA port, 2 x USB 3.0 ports, and 2 x RJ45 GbE ports. Front Panel I/O on the 8HP
XTM layer have multiple options; 8HP XTM-1 board provides 1x RJ45 COM port, 1 x
HDMI display port, 1 x USB 3.0 port, 2 x GbE LAN ports by M12 X-coding or RJ45
connectors; 8HP XTM-2 Board provides 4 x GbE LAN ports by M12 X-coding or
RJ45 connectors.
MIC-3332 provides an ideal solution for transportation, railway, and factory Automa-
tion applications. With its robust board layout and thermal efficiency, it meets and
exceeds EN50155 and EN50121-4 standards.
MIC-3332 series can be installed in a standard CompactPCI system slot, designed to
meet harsh environments, and is ideally suitable for data centers, telecom, military,
defense systems, and many other vertical segment applications. It is compliant with
PICMG 2.0 Rev. 3.0/PICMG 2.1/PICMG 2.3 Rev.1.0, and supports 32-bit/33 MHz
PCI bus at +3.3 V or +5 V VIO.
Ordering Information:
Single
board
Front Panel Main On board Features
4HP 8HP XTM 4HP
8HP XTM
(Conn./Socket/Pin head)
Others
LAN
(RJ45)
USB
3.0
VGA
LAN
(M12)
LAN
(RJ45)
COM HDMI
USB
3.0
CPU Memory
SATA
Conn.
Cfast
Socket
Micro-SD
Socket
COM-
Pin
head
Slot
Width
PlusIO
MIC-
3332C1-
D1E
2 2 1 - 4 - - -
i7-
6822E
Q
8GB 1 1 1 - 2 No
MIC-
3332D1-
D1E
2 2 1 4 - - - -
i7-
6820E
Q
16GB 1 1 1 - 2 No
MIC-
3332C4-
D2E
2 2 1 - 2 1 1 1
i7-
6822E
Q
8GB 1 1 - 1 2 No
MIC-
3332C5-
D2E
2 2 1 2 - 1 1 1
i7-
6822E
Q
16GB 1 1 - 1 2 No
