7 MIC-330 User Manual
Chapter 1 Hardware Configuration
1.2.15 M/D, PWR, HDD, Hot-swap & LAN LEDs
Front panel provide Many LEDs for indication, please check details as below table:
1.2.16 CompactPCI
®
Serial Backplane Resources
MIC-330 is a CPU card that followed PICMG® CPCI-S.0 standard, and provides high
speed Interfaces for peripheral card extension, as shown below:
Table 1.5: Front Panel LEDs Indication
Layer Name Description
4HP
PWR (Green) Indicates power status
HDD (Yellow) Indicates HDD Read/Write
H/S (Blue)
Indicates the board is ready to be hot-
swapped
M/D (Blue)
Indicates Master or Drone mode status
Blue blink Indicates the board is inserted
into peripheral slots
LAN1/LAN2(Link)
1000Mb/s:Orange;100Mb/s: Green;10Mb/
s: LED off
LAN1/LAN2 (Activity) Green Blink
Mezzanine-1 Card LAN3/4(Activity) Green Blink
Mezzanine-2 Card
L3/L4(Link)
1000Mb/s: Orange; 100Mb/s: Green;10Mb/
s: LED off
A3/A4/A5/A6/A7(Activity) Green Blink
Table 1.6: Interfaces to Backplane
CPCI-S connector Interfaces
P1 1 x PEG x 4; 1 x USB 3.0; 1 x USB 2.0
P2 1 x PEG x 4; 1 x PEG x 8; 3 x USB 2.0
P3 4 x SATA 3.0; 1 x USB 3.0; 4 x USB 2.0
P4 2 x PCIe x 4; 2 x PCIe x 1
P5 System Clock
P6
2 x GbE on M-1 side card
Max 5 x GbE on M-2 side card
(2x GbE switch with 2x M12 LAN on front 8HP)
