MIC-330 User Manual 4
1.2.4 Memory
Integrated memory controller up to dual channel, 32GB/2666MHz frequency support.
DDR4 soldered memory up to 16GB
Another ECC SO-DIMM memory module socket up to 16GB,
total 32GB on a single board
The following table lists the SO-DIMM modules that have been tested with MIC-330.
1.2.5 Graphics
Integrated graphics engine with max 3 independent displays in processor
Front panel options: Default 2 x DisplayPort (DP) connectors or 1 x VGA con-
nector (reserved on M-1), per use request
Resolution:
– 4096 x 2304 @30Hz (DisplayPort) with E-2276ME/E-2276ML CPU
– 4096 x 2304 @60Hz (DisplayPort) with Core i7-9850HL/i7-9850HE/i3-
9100HL CPU
– 1920 × 1080 @60Hz (VGA)
1.2.6 Ethernet
MIC-330 is equipped with several high-performance PCI-Express based network
interface controllers which provide full IEEE802.3 compliant 10/100/1000Base-TX
Ethernet interfaces.
Up to 7 Ethernet networking interfaces in total.
2 x front RJ45 GbE, 2 x GbE interfaces to backplane P6 on M-1 side card (4HP
front panel width).
2 x front RJ45 GbE, 2 x M12 X-code GbE, 3 x GbE interfaces to backplane P6
on M-2 side card (2x M12 X-code GbE on front 8HP can switch to 2 x GbE inter-
faces to backplane P6).
Table 1.2: So-DIMM Modules Type
Brand Size Speed Vendor Part Number ECC Pin Count
Advantech 8GB DDR4-2666 AQD-SD4U8GE26-SE ECC 260 pin
Advantech 16GB DDR4-2666 AQD-SD4U16E26-SE ECC 260 pin
Kingston 4GB DDR4-2400
4GB DDR4 2400 SO-DIMM_
KVR24S17S6/4
Non-ECC 260 pin
Micron 4GB DDR4-2666
4GB DDR4 2666 SO-DIMM 1RX16
MTA4ATF51264HZ-2G6E1
Non-ECC 260 pin
Kingston 16GB DDR4-2666 16GB DDR4 2666_ CBD26D4S9D8ME Non-ECC 260 pin
Micron 8GB DDR4-3200
8G DDR4 3200 MTA8ATF1G 64HZ-
3G2J1 1RX8
Non-ECC 260 pin
Kingston 16GB DDR4-3200 16G DDR4 3200 CBD32D4 S2S8HA-16 Non-ECC 260 pin
Note! ECC support is optional on different processor spec. Please consult
your local sales.
