www.advantech.com
7
⚫ Software: Go to Toolbox menu “Device Settings > Basic > Basic Settings” to select screen
display mode.
2.4 Button and Traffic Light
Function
Action
Light Status
Power ON/OFF
Press and hold the power button for more
than 3 seconds.
Power On: Off → On
Power Off: On → Off
Switch Screen
Display Mode
Quick press the power button once.
Blinks once
Reset to Factory
Default
Press and hold the reset button for more
than 10 seconds.
Quickly Blinks
Air Quality Level
Indication
Indicate the 3 levels of air quality according
to threshold setting. When one of the
concentrations of air pollutants of CO
2
,
TVOC, PM2.5, PM10 or HCHO exceeds the
threshold, the light color will change to
orange or red
Excellent: Blinks/Always
On (Configurable)
Polluted: Blinks/Always
On (Configurable)
Bad: Blinks/Always On
(Configurable)
Note:
⚫ If the traffic light is disabled, it will not show air quality level indication.
⚫ LEO-S592-AQG0 supports Traffic Light as Blinking or Always On to indicate Polluted or Bad
indoor ambience.
2.5 Dimensions(mm)
3. Power Supply
1. Release the screw at the back of device and remove the rear cover.
2. Install the batteries or type-C cable to the device. If the device is powered via type-C port, then
left or right side should make an opening to pass through the type-C cable.
