3 ITA-580/580G User Manual
Chapter 1 Overview
Dimensions (W x H x D):
– ITA-580: 260 x 88 x 197.2 mm/10.24 x 3.46 x 7.76 inch
314.7 x 95 x 197.2 mm/12.36 x 3.74 x 7.76 inch (with mounting kit)
– ITA-580G: 260 x 140.9 x 197.2 mm/10.24 x 5.51 x 7.76 inch
296 x 142.9 x 197.2 mm/11.7 x 5.6 x 7.76 inch with mounting kit
Net Weight:
– ITA-580: 4.5KG/9.92 lbs
– ITA-580G: 6.5KG/14.33 lbs
1.3 System Power
Input Voltage: Wide range power-in 24V
DC
~ 110V
DC
(±40%)
Power supply information of EN 50155:
Supply interruption (Performance criterion: A): S3: 110V
DC
/S2:24V
DC
~
110V
DC
Supply change over (Performance criterion: A): C2: 110V
DC
/C1: 24V
DC
~
110V
DC
Power Consumption: Power input voltage at 24V
DC
Idle mode: 35 Watt
Burn-in: 65 Watt
Max. load mode: 91 Watt
Circuit breaker recommendation:
– ITA-580: select 10 ampere
– ITA-580G: select 20 ampere
ITA-580 power behavior
1.4 Safety and Environment
1.4.1 Safety and Compliance
1.4.1.1 Safety
CE, CCC, BSMI, FCC class A, UL 62368
1.4.1.2 Rolling Stock
EN 50155:2021, EN 50121-3-2, EN 50121-4,EN 45545-2:2020 HL3, NFPA 130
1.4.2 Environment
Operating Temperature:
– ITA-580: -40 ~ 70 °C/-40 ~ 158 °F (85 °C/185 °F for 10 minutes) with indus-
trial grade peripheral device
– ITA-580G: Operating Temperature: -40 ~ 70 °C/-40 ~ 158 °F (85 °C/185 °F
for 10 minutes) with industrial grade peripheral device; With 60-watt of MXM
module: EN 50155:2021 OT1 (-25 ~ 55°C)
Storage Temperature: -40 ~ 70 °C/-40 ~ 158 °F
Note! The power consumption may different depends on the configuration.
