ITA-460 User Manual 2
1.1 Introduction
ITA-460 is a compact and vehicle computer equipped with a 8th/9th generation
Intel® CoreTM i processor, wide voltage input range and special power protection
surges design guarding against system damage from transient power. Specifically
designed for intelligent transportation and road surveillance applications, It can work
in extreme environments with features like the wide working temperature range (-25-
60°C) and anti-shock/vibration to pass MIL-STD-810G; this power- ful computing
platform can withstand 24/7 operation.
1.2 Specifications
CPU: Intel® 8th/9th Gen Core™ i CPU socket (LGA1151)
PCH: Intel® H310 chipset
System Memory: Onboard 8/16 GB DDR4 2400/2666 MHz and One SO-RIMM
memory socket up to 32GB
Graphic: H310: Intel® HD Graphics 610, supports DirectX 12
Display: HDMI : 3840x2160 @ 30 Hz
Storage: Supports 2 x 2.5" SSD and 1 x Full-size mSATA (on main board)
Expansion: 3 x Full-size mini PCIe ( 1 with SIM card slot for WWAN)
Watchdog Timer: Single chip watchdog 255-level interval timer, setup by soft-
ware
Ethernet: 2 x 10/100/1000Mbps with M12 X-coded (F) controller: Intel I210-IT
USB: 2 x USB 3.0 (Type A)
Series I/O: 2 x RS-232/422/485, auto-flow control, DB9 type
Audio: High Definition Audio (HD) by M12 A coded x 1 (1 x line out and 1 x mic
in)
Dimensions (W x H x D): 190 x 70 x 220 mm
Net Weight: 4 kg
1.3 Power Information
Table 1.1: Power Input
DC-In Voltage 12V / 24V
Voltage Range 9 ~ 32V (Power input constraint at low power 8~9.6V)
Power Consumption
Typical: 33W
Maximum: 95W
Power Connector 1 x M16 (M) 6-pin
