ITA-3650G Series Startup Manual 3
DIOConnectorDenition
The IPC has a DB25 DIO connector, which provides a
12-channel digital input connector and a 12-channel digital
output connector. The denition is as follows:
DIO
PinDenition
Pin 1 - Pin 12 Digital input (Input)
Pin 13 GND
Pin 14 - Pin 25 Digital output (Output)
DIO Connector
PowerConnectorDenition
The IPC has a 4-channel Phoenix power input connec-
tor, which provides 9 ~ 36 V DC voltage to the board. The
denition is as follow:
Phoenix Connecor DC Input
PinDenition
Pin 2/3 Positive
Pin 1/4 GND
DC Power Input Connector
LEDDenition
At the top right corner on the rear side, there are 3 LEDs
indicating the operating status.
LED Status
LED Status
Storage LED Orange
Power/Alarm LED Green/Red
ConnectorDenition
EthernetLEDDenition
The IPC has serial RJ45 Ethernet connectors, with LEDs
showing network status.
LAN
LED Status
1000 MB Green (top left LED)
100 MB Orange (top left LED)
Connection Status Green lckering (top right LED)
RJ45 Connector
