IPC-610 User Manual/ 用户手册 30
4.2.2 Switch Settings/ 开关设置 / 開關設定
Table 4.6: CN18, Output connector to LED board/LED 板输出接口連接 /LED
板的輸出接頭
Pin 1 GND Pin 9 Temperature Good
Pin 2 +5 V signal Pin 10 Temperature Fail
Pin 3 +12 V signal Pin 11 FAN Good
Pin 4 -5 V signal Pin 12 FAN Fail
Pin 5 -12 V signal Pin 13 N/A
Pin 6 HDD_1 Pin 14 +3.3 V signal
Pin 7 Power Good Pin 15 +5 Vsb signal
Pin 8 Power Fail
Table 4.7: CN26, External HDD LED connector/硬盘LED接口/硬碟LED接頭
Pin 1 HLED_ACT Pin 2 N/A
Table 4.8: FAN1~FAN7, Fan connectors/ 风扇接口 / 風扇接頭
Pin 1 GND Pin 3 FAN_DEC
Pin 2 +12 V
Table 4.9: J1, External Buzzer/ 外部蜂鸣器 / 外部蜂鳴器
Pin 1 Buzzer Pin 2 +5 V
Table 4.10: SW1, Fan number select switch/ 风扇数量选择开关 / 風扇數量
選擇開關
Pin 1 GND Pin 5 GND
Pin 2 FAN_SEL1 Pin 6 FAN_SEL3
Pin 3 GND Pin 7 GND
Pin 4 FAN_SEL2 Pin 8 RESET
Table 4.11: SW1, Fan number setting/ 风扇数量设置 / 風扇數量設定
Fan Number SW 1-1 SW 1-2 SW 1-3 SW 1-4
0 OFF OFF OFF OFF
1ONOFFOFFOFF
2 (default/默认 /預設)
OFF ON OFF OFF
3ONONOFFOFF
4 OFF OFF ON OFF
5 ON OFF ON OFF
6 OFF ON ON OFF
7ONONONOFF
