5 IPC-610 User Manual/ 用户手册
Chapter 1 General Information 概述 產品資訊
1.3.2 Dimension Diagram/ 产品尺寸 / 產品尺寸
Figure 1.3 IPC-610-F: Dimension diagram/ 产品尺寸 / 產品尺寸
1.4 IPC-610-E
1.4.1 Specifications/ 产品规格 / 產品規格
Power supply
options
电源选项
電源選項
PS-250ATX-ZE, PS-300ATX-ZBE, PS-400ATX-ZBE, PS-500ATX-ZE,
P S -7 0 0AT X -Z E ( MB o nl y ) , P S -3 0 0AT X -D C 4 8E , RP S -3 0 0 AT X - Z E,
RPS-400ATX-ZE
Table 1.2: Specifications/ 产品规格 / 產品規格
Unit: mm [inch]
motherboard backplane
Table 1.3: Specifications/ 产品规格 / 產品規格
Drive Bay
驱动支架
磁碟機
3.5” 3
5.25” 2
Cooling
冷却
散熱
Fan
风扇
風扇
1 (85 CFM)
Air Filters
空气过滤器
濾網
Yes
Front I/O Interface
前部 I/O 接口
前方 I/O 接頭
K/B Connector 1(front-accessible 5-pin DIM connector)
Miscellaneous
其它
其他
LED Indicator
LED 指示灯
LED 指示燈
Power, HDD and Keyboard-Lock
1 D-SUB 9-pin, 1 D-SUB 25-pin and 1 AT key-
board connector reserved openings
