33 IPC-6025 User Manual/ 用户手册
Chapter 4 Alarm Board 报警板
4.2.2 DIP Switch Setting/DIP 开关设定 /DIP 開關設定
DIP Switch on IPC-6025 alarm board
Pin 3 - Pin 5, Switch setting; For CPU and CPU Cooler quantity defined
IPC-6025 报警板上的 DIP 开关
针脚 3 - 5 开关设定；主板上的 CPU 数量、CPU 温度设定
IPC-6025 報警板上的 DIP 開關
針腳 3 - 5 開關設定；主板上的 CPU 數量、CPU 溫度設定
Pin 1 - Pin 2, Switch setting; for System Fan quantity defined
针脚 1 - 2 开关设定；系统风扇数量设定
針腳 1 - 2 開關設定；系統風扇數量設定
Pin 6, Switch setting; for SMART Fan Control defined
针脚 6, 开关设定；系统风扇转速控制设定
針腳 6 開關設定；系統風扇轉速控制設定
JSW3.Pin3 JSW4.Pin4 JSW5.Pin5 MB FAN CPU TEMP
OFF OFF OFF Disable Disable
OFF OFF ON Disable 1
OFF ON OFF Disable 2
OFF ON ON 1 1
ON OFF OFF 2 1
ON OFF ON 2 2
ON ON OFF 3 1
ON ON ON 3 2
SYSTEMFAN&TEMP
JSW1.Pin1 JSW2.Pin2 SYSTEMFAN SYSTEMTEMP
OFF OFF Disable
1
OFF ON 1
1
ON OFF 2
1
ON ON Disable
Disable
SMARTFANControl
JSW6.Pin6 Function
OFF Enable
ON Disable
