IDP31-070WP50(1K)HIA1 User Manual 6
2.1 Specifications
Note! The IDP31-070WP50(1K)HIA1 offers the following features.
Unless otherwise indicated, all the specifications listed below are sub-
ject to change without prior notification.
Table 2.1: Specifications
Display
Features
Specifications Notes
Model IDP31-070WP50HIA1 IDP31-070WP1KHIA1
Backlight LED LED Light source
Resolution 800 x 480 800 x 480
Brightness
500 cd/m
2
1000 cd/m
2
Viewing Angle 85°/85°/85°/85° 85°/85°/85°/85° Left/Right/Up/Down
Max Colors 16.7M 16.7M
Contrast
Ratio
800:1 800:1
Response
Time
25 ms 25 ms Maximum
Backlight
Lifetime
50,000 hours 50,000 hours
Typical time to half
brightness in room tem-
perature operation
Touchscreen
Type
Projected Capacitive Projected Capacitive 10 points
Surface
Hardness
7H 7H Pencil hardness
Transparency 90% 90% Minimum
Cover Glass
Thickness
2.8 mm 2.8 mm
Operating
Temperature
-20 ~ 65°C -20 ~ 65°C
Storage
Temperature
-30 ~ 80°C -30 ~ 80°C
Humidity 90% @ 40°C (104°F) 90% @ 40°C (104°F) Non-condensing
Input/Output
HDMI x 1; 12 VDC Jack x
1; Type A USB x 1
HDMI x 1; 12 VDC Jack x
1; Type A USB x 1
OSD
Keys: Menu/Sel, Right/
UP, Left/Down, Exit, Mon-
itor Power on/off
Key Functions: Bright-
ness,Contrast, Screen
Settings, Color Temp,
Language
Keys: Menu/Sel, Right/
UP, Left/Down, Exit, Mon-
itor Power on/off
Key Functions: Bright-
ness, Contrast, Screen
Settings, Color Temp,
Language
Power
Consumption
4W 5.5W
Power Input
12V
DC
12V
DC
Mounting VESA/Panel mount VESA/Panel mount
IP Rating Front IP67 Front IP67
Net Weight 1.22 kg 1.22 kg
IK08 Front side surface only Front side surface only
