IDK-2121W User Manual 2
1.1 General Description
IDK-2121W series is a Color Active Matrix Liquid Crystal Display composed of a TFT-
LCD panel, a driver circuit, and backlight system. The screen format is intended to
support the FHD (1920 (H) x 1080 (V)) screen and 16.7M colors (RGB 8-bit data). All
input signals are dual-LVDS interface. Driver board for the backlight is included.
1.2 Display Characteristics
The following are characteristics offer a summary under 25°C condition:
Table 1.1: Display Characteristics
Item Unit Description
Screen Diagonal [mm] 546.86 (21.53”)
Active Area [mm] 476.64 (H) x 268.11 (V)
Pixels H x V 1920 (x3) x 1080
Pixel Pitch 248.25 (per one triad) × 248.25
Pixel Arrangement [um] RGB Vertical Stripe
Display Mode VA Mode, Normally Black
White Luminance (Center)
[cd/m
2
]
1200 (Typ.)
Contrast Ratio 5000:1 (Typ.)
Optical Response Time [msec] 25 ms (Typ., on/off)
Input Voltage VDD [Volt] +5.0 V
Backlight Input Voltage [Volt] +12.0 V
Power Consumption
(VDD line + LED line)
[Watt] 46.8 (Typ.)
(with LED driver board, all white pattern)
Weight [Grams] R series: 3200 (Typ.)
N series: 2400 (Typ.)
Physical Size [mm] R series: 495.6(W) × 292.2(H) × 15.58(D) Typ.
N series: 495.6(W) × 292.2(H) × 11.63(D) Typ.
Electrical Interface Dual channel LVDS
Support Color 16.7M colors (RGB 8 bits)
Surface Treatment Anti-Glare, 3H
Temperature Range
Operating
Storage (Shipping)
[°C]
[°C]
N-series/R series
0 to 55
0 to 60
RoHS Compliance RoHS Compliance
