IDK-2110R XGA User Manual 18
4.1 TFT LCD Signal(CN1): LVDS Connector
4.2 LED Backlight Unit Connector(CN3)
Table 4.1: Connector
Connector Name / Description Signal Connector
Manufacturer I-PEX or compatible
Connector Model Number 20186-020E-11F or Compatible
Adaptable Plug 20197-020U-F, 20197-T20U-F or compatible
Table 4.2: Pin Assignment
Pin No. Signal Name Pin No. Signal Name
1 VDD 2 VDD
3GND 4 GND
5RxIN0- 6 RxIN0+
7 GND 8 RxIN1-
9 RxIN1+ 10 GND
11 RxIN2- 12 RxIN2+
13 GND 14 CK IN1-
15 CK IN1+ 16 GND
17 RxIN3- 18 RxIN3+
19 MODE 20 SC
Connector Name / Designation LED Light Bar Connector / Backlight lamp
Manufacturer JST or compatible
Connector Model Number SM06B-SHLS-G-TF(LF)(SN) or compatible
Mating Model Number SHLP-6V-S-B or compatible
Pin No. Symbol Description
Pin1 VIN +12V power supply
Pin2 VIN +12V power supply
Pin3 BLBRT PWM
Pin4 BLEN ON/OFF terminal voltage
Pin5 GND GND
Pin6 GND GND
