IDK-2110 User Manual 18
4.1 TFT LCD Module
Physical interface is described as for the connector on module. These con-
nectors are capable of accommodating the following signals and will be fol-
lowing components.
4.1.1 Connector
4.1.2 Pin Assignment
4.2 Backlight Unit
Physical interface is described as for the connector on module. These connectors are
capable of accommodating the following signals and will be following components.
4.2.1 Signal for LED light bar connector
Cable Length: 250mm+/-10mm
Table 4.1: Connector
Connector Name / Description Signal Connector
Manufacture STM or compatible
Connector Model Number STM-MSB24013P20HA or Compatible
Adaptable Plug STM-P24013P20 or compatible
Table 4.2: Pin Assignment
Pin No. Signal Name Pin No. Signal Name
1 VDD 2 VDD
3GND 4 DPS
5RxIN0- 6 RxIN0+
7 GND 8 RxIN1-
9 RxIN1+ 10 GND
11 RxIN2- 12 RxIN2+
13 GND 14 RxCLKIN-
15 RxCLKIN+ 16 GND
17 RxIN3- 18 RxIN3+
19 RSV 20 SEL68
Connector Name / Designation LED Light Bar Connector / Backlight lamp
Manufacturer SPEEDCON
Type Part Number WF-SMT90 1.5mm Wire to board Heater
Mating Type Part Number NA
Connector No. Pin No. Input Color Function
Lower
CN2
1 HI 2 Red Power supply for backlight unit
2 GND 2 Black Ground for backlight unit
