IDK-2110P-1KXGA1 User Manual 26
A.1 Test Conditions
A.2 Optical Specifications
The relative measurement methods of optical characteristics are shown in A.2. All
items are measured at the center point of the screen, except for the white variation.
The following items should be measured under the testing conditions described in
A.1 and a stable environment as shown in Note (5).
Definition:
Grayscale Maximum: Grayscale 255 (10-bit: grayscale 1023; 8-bit: grayscale 255; 6-
bit: grayscale 63)
White: Luminance of grayscale Maximum (All R,G,B)
Black: Luminance of grayscale 0 (All R,G,B)
Item Symbol Value Unit
Ambient Temperature Ta 25±2 ºC
Ambient Humidity Ha 50±10 %RH
Supply Voltage
According to typical value and tolerance in
"electrical characteristics"
Input Signal
PWM Duty Ratio D 100 %
Item Symbol Condition Min. Typ. Max. Unit Note
Color
Chromaticity
Red
Rx
ɵX=0º, ɵY =0º
Grayscale
Maximum
0.599 0.649 0.699
- (1), (5)
Ry 0.290 0.340 0.390
Green
Gx 0.270 0.320 0.370
Gy 0.556 0.606 0.656
Blue
Bx 0.099 0.149 0.199
By 0.005 0.055 0.105
White
Wx 0.263 0.313 0.363
Wy 0.279 0.329 0.379
Center Luminance of White LC 800 1000 - (4), (5)
Contrast Ratio CR 700 1000 - (2), (5)
Response Time
TR ɵX=0º, ɵY =0º - 13 18 -- (3)
TF - 12 17
White Variation δW ɵX=0º, ɵY =0º 72 80 - % (5), (6)
Viewing Angle
Horizontal
ɵX+ CR≥10 80 88 - Deg. (1), (5)
ɵX- 80 88 -
Vertical
ɵY+ 80 88 -
ɵY- 80 88 -
