IDK-2108 User Manual 22
5.1 Touchscreen (Optional: for IDK-2108R Only)
5.1.1 Touch Characteristics
The touch panel is a resistance type that customers use with flat displays like LCDs.
Once an operator touches it, the circuit will send coordinate points to the PC from the
voltage changes at the contact points.
5.1.2 Optical Characteristics
5.1.3 Environmental Characteristics
5.1.4 Mechanical Characteristics
5.1.5 Electronic Characteristics
Item Specifications Remarks
1 TRANSPARENCY 82.5% Typ. 80% Min. (Active area)
(Inside of guaranteed active area)
JIS K-7105
2 HAZE 8.0% Typ. (Anti-glare) JIS K-7105
Item Specifications Remarks
1 Operational temperature -10°C ~ 60°C Max. wet temp is 38°C
(No dew)
2 Storage temperature -30°C ~ 70°C
3 Operational Humidity 20% ~ 90%RH
4 Storage temperature 10% ~ 90%RH
Item Specifications Remarks
1 Hardness of surface Pencil hardness 3H. JIS K-5600-5-4
150gf, 45 degree
2 FPC peeling strength 1) 5N (5N Min.)
2) 19.6N (19.6N Min.)
1) Peeling upward by 90°
2) Peeling downward by 90°
3 Operational force Pen 0.05N~1.96N
(5~200gf)
Dot-Spacer
Within “guaranteed active
area”, but not on the age and
Dot-Spacer.
Finger
Item Specification Remarks
1 Rated Voltage DC 7V max.
2 Resistance X axis: 200 ~ 1000(Glass side) FPC connector
Y axis: 100 ~ 800(Film side)
3 Linearity ±1.5%max initial value
±2.0%max (after environmental & life test)
Reference: 250gf
4 Chattering 20ms Max
At connector pin
5 Insulation
Resistance
10M @ (DC 25V)
10M min (DC 25V)
