13 IDK-2108 User Manual
Chapter 3 Signal Characteristics
3.4 Interface Timing
3.4.1 Timing Characteristics
Note: Frame rate is 60 Hz.
Note: DE mode.
3.4.2 Input Timing Diagram
3.5 Power ON/OFF Sequence
VDD power and Backlight on/off sequence is as follows. Interface signals are also
shown in the chart. Signals from any system shall be Hi-Z state or low level when
VDD is off.
Table 3.2: Timing Characteristics Table 3.3:
Signal Parameter Symbol Min. Typ. Max. Unit
Clock Timing Clock frequency 1/ T
Clock
33.6 39.8 48.3 MHz
Vsync Timing
Vertical
Section
Period T
V
608 628 650 T
H
Active T
VD
600 600 600 T
H
Blanking T
VB
82850T
H
Hsync Timing
Horizontal
Section
Period T
H
920 1056 1024 T
Clock
Active T
HD
800 800 800 T
Clock
Blanking T
HB
120 256 440 T
Clock
