IDK-1119R User Manual 2
1.1 General Description
IDK-1119R-35SXA1E is a Color Active Matrix Liquid Crystal Display composed of a
TFT-LCD panel, a driver circuit, and backlight system. The screen format is intended
to support the SXGA (1280H x 1024V) screen and 16.7M colors (RGB 6-bits with
HiFRC data). All input signals are LVDS interface compatible. Driver board of back-
light is included.
1.2 Display Characteristics
The following items are characteristics summary on the table under 25°C condition:
Items Unit Specifications
Screen Diagonal [mm] 482.6 (19.0")
Active Area [mm] 376.32 (H) x 301.06 (V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.294 (per one triad) x 0.294
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance
[cd/m
2
]
350
Contrast Ratio 1000 : 1 (Typ)
Optical Response Time [msec] 5 ms (Typ, on/off)
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption [Watt] 20.55 W
(PDD= 5.5W @LED=80mA)
Weight [Grams] 2750 (Typ)
Physical Size (H x V x D) [mm] 396 (H) x 324 (V) x 20.7 (D) (Typ)
Electrical Interface Dual channel LVDS
Surface Treatment Anti-Glare treatment
Support Color 16.7M colors (RGB 6-bit data + HiFRC data)
Temperature Range
Operating
Storage (Non-Operating)
[
°C]
[
°C]
0 to +50
-20 to +60
RoHS Compliance RoHS Compliance
