IDK-1115WP-45FHA2 User Manual 16
2.8 Pin Description
Table 2.2: Pin Assignment
Pin Name Description
1 LED _Vcc +12V Vi power supply
2 LED _Vcc +12V Vi power supply
3 LED _Vcc +12V Vi power supply
4 LED _Vcc +12V Vi power supply
5 GND Ground
6 GND Ground
7 GND Ground
8 GND Ground
9 LED_EN Enable pin
10 LED_PWM Backlight Adjust
11 LCD_VCC LCD logic and driver power 3.3V
12 LCD_VCC LCD logic and driver power 3.3V
13 LCD_VCC LCD logic and driver power 3.3V
14 NC No connection, this pin should be open
15 NC No connection, this pin should be open
16 NC No connection, this pin should be open
17 LCD GND LCD logic and driver ground
18 RXO0- Negative LVDS differential data input. Channel O0 (odd)
19 RXO0+ Positive LVDS differential data input. Channel O0 (odd)
20 RXO1- Negative LVDS differential data input. Channel O1 (odd)
21 RXO1+ Positive LVDS differential data input. Channel O1 (odd)
22 RXO2- Negative LVDS differential data input. Channel O2 (odd)
23 RXO2+ Positive LVDS differential data input. Channel O2 (odd)
24 LCD GND LCD logic and driver ground
25 RXOC- Negative LVDS differential clock input. (odd)
26 RXOC+ Positive LVDS differential clock input. (odd)
27 LCD GND LCD logic and driver ground
28 RXO3- Negative LVDS differential data input. Channel O3(odd)
29 RXO3+ Positive LVDS differential data input. Channel O3 (odd)
30 RXE0- Negative LVDS differential data input. Channel E0 (even)
31 RXE0+ Positive LVDS differential data input. Channel E0 (even)
32 RXE1- Negative LVDS differential data input. Channel E1 (even)
33 RXE1+ Positive LVDS differential data input. Channel E1 (even)
34 LCD GND LCD logic and driver ground
35 RXE2- Negative LVDS differential data input. Channel E2 (even)
36 RXE2+ Positive LVDS differential data input. Channel E2 (even)
37 RXEC- Negative LVDS differential clock input. (even)
38 RXEC+ Positive LVDS differential clock input. (even)
39 RXE3- Negative LVDS differential data input. Channel E3 (even)
40 RXE3+ Positive LVDS differential data input. Channel E3 (even)
