IDK-1115P User Manual 20
4.1 TFT LCD Module
Below, the physical interface is described for the connector on module. These
connectors are capable of accommodating the following signals and compo-
nents.
4.1.1 Connector
4.1.2 Interface Pin Assignment
4.1.3 Backlight Unit Pin Assignment
Table 4.1: Connector
Connector Name LCM Connector
Part Number
User’s Connector
Part Number
Interface connector Cvilux CID520D1HR0-NH or
equivalent
Hirose DF14-20S-1.25C or
equivalent
Back light connector Cvilux CI4205M2HRP-NH or
equivalent
Cvilux CI4205SL000 or equiva-
lent
Table 4.2: Pin Assignment
Pin No. Symbol Pin No. Symbol
1VCC 11RX2-
2VCC 12RX2+
3NC 13GND
4 LR/UD 14 RXCLK-
5 RX0- 15 RXCLK+
6RX0+ 16GND
7 GND 17 RX3-
8 RX1- 18 RX3+
9RX1+ 19NC
10 NC 20 SEL68
Pin Symbol Description Remark
1 Vi Converter input voltage 12V
2 VGND Converter ground Ground
3 EN Enable pin 3.3V
4 Dimming Backlight adjust PWM dimming
(Hi: 3.3VDC, Lo: 0VDC)
5 NC Not Connect
