IDK-1112R-50XGA1 User Manual 2
1.1 General Description
The Advantech IDK-1112R-50XGA1 comes with a 12.1" industrial grade LCD display
with 5-wire resistive touch.
1.2 Specifications
1.2.1 LCD Panel
Display Size: 12.1", 4:3
Resolution: 1024 x 768
Display Mode: Normally Black (IPS like)
Viewing Angle (Horizontal/Vertical): 178°/178°
Brightness: 500 cd/m
2
Contrast Ratio: 1000:1
Response Time: 25 ms
Colors: 262k (6bit) / 16.7M (8bit)
LCD Nominal Input Voltage / Current: 3.3V / 370mA
Backlight Input Voltage/ Current: 12V / 0.7A
Power Consumption: 9.62W (white pattern)
Signal Interface: LVDS
Weight: 490g
Dimensions (W x H x D): 260.5 x 204 x 8.4mm
1.2.2 Touch Screen
Touch Screen: 5-wire Resistive
Light Transmission: 80 2%
Interface: USB
Surface Hardness: 3H
Durability: 10 million times
1.2.3 Environment
Operating Temperature: -20 ~ 70°C
Storage Temperature: -30 ~ 80°C
Note! Temperature and relative humidity range is shown in the figure below.
90% RH Max. (Ta
≤40 °C).
Wet-bulb temperature should be 39 °C Max. (Ta > 40 °C).
