13 IDK-1110R-50XGB1 User Manual
Chapter 2 LCD Display
2.5 Input Terminal Pin Assignment
2.5.1 TFT LCD Module
Table 2.3: Pin Description
Pin No. Symbol Description Note
1 VCC Power supply: +3.3V -
2 VCC Power supply: +3.3V -
3 VCC Power supply: +3.3V -
4 GND Ground -
5 GND Ground -
6 GND Ground -
7 RPFI Reverse Panel Function (Display Rotation) ( 3 )
8 NC No Connection ( 4 )
9 NC No Connection ( 4 )
10 NC No Connection ( 4 )
11 SEL6/8
LVDS 6/8 bit select function control,
Low or NC -> 8 bit Input Mode
High -> 6bit Input Mode
( 3 )
12 GND Ground -
13 NC No Connection ( 4 )
14 GND Ground -
15 RX0- Negative transmission data of pixel 0 -
16 RX0+ Positive transmission data of pixel 0 -
17 GND Ground -
18 RX1- Negative transmission data of pixel 1 -
19 RX1+ Positive transmission data of pixel 1 -
20 GND Ground -
21 RX2- Negative transmission data of pixel 2 -
22 RX2+ Positive transmission data of pixel 2 -
23 GND Ground -
24 RXCLK- Negative of clock -
25 RXCLK+ Positive of clock -
26 GND Ground -
27 RX3- Negative transmission data of pixel 3 -
28 RX3+ Positive transmission data of pixel 3 -
29 GND Ground -
30 NC No Connection ( 4 )
Note (1) Connector Part No.: P-TWO 187106-30091 or STM, MSCK2407P30.D
or equivalent.
Note (2) User's connector Part No.: JAE FI-X30H(L) or equivalent.
