25 IDK-1110P-50XGB1 User Manual
Chapter 3 Touchscreen and Touch Controller
Positional Accuracy: The accuracy specifications are based on PenMount
touch panel controllers and drivers to define, the percentage of positional inac-
curacy is less than 1.0% as defined below.
– X direction of linearity: Δx/X *100%.
– Y direction of linearity: Δy/Y *100%.
Electrostatic Discharge Protection: (according to IEC 61000-4-2, level 4/
class B)
– Air discharge:15KV(maximum)
Static electricity comes from the touch side of the touch panel
– Contact discharge: 8KV(maximum)
Static electricity comes from the touch side of the touch panel
3.2.2 Pin Assignment and Description
3.3 Typical Optical Characteristics
Visible Light Transmission: 90±3%
Haze: < 3%
Note! Testing result are highly relevant to mounting methods.
