IDK-1110R-50XGB1 User Manual 26
3.11 Touch Characteristics
This touch panel is of a resistance type that customers use with flat displays like
LCDs. Once an operator touches it with a stylus or finger, the circuit sends coordinate
points to the PC in voltages from the contact point.
3.12 Optical Characteristics
3.13 Environmental Characteristics
3.14 Mechanical Characteristics
3.15 Electronic Characteristics
Item Specification Remarks
1 Transparency
82.5% Typ. 80% Min. (active area)
(Inside of guaranteed active area)
JIS K-7105
2 Haze 8.0% Typ. (anti-glare) JIS K-7105
Item Specification Remarks
1 Operation Temperature
-10 ~ 60
°C
Max. wet temp. is 38
°C
(no dew)
2 Storage Temperature
-30 ~ 70°C
3 Operation Humidity 20% ~ 90%RH
4 Storage Temperature 10% ~ 90%RH
Item Specification Remarks
1 Hardness of Surface Pencil hardness 3H.
JIS K-5600-5-4
150gf, 45°
2 FPC Peeling Strength
1) 5N (5N Min.)
2) 19.6N (19.6N Min.)
1) Peeling upward by 90°
2) Peeling downward by
90°
3 Operation Force
Pen
0.05N~1.96N
(5~200gf)
Dot-Spacer
Within a "guaranteed
active area", but not on the
edge and dot-spacer.
Finger
Item Specification Remarks
1 Rated Voltage DC 7V max.
2 Resistance
X axis: 200
~ 500(glass side)
FPC connector
Y axis: 200 ~ 800(film side)
3 Linearity
1.5% max (initial value)
2.0% max (after environmental &
life test)
Reference: 250 gf
4 Chattering
20ms max.
At connector pin
5 Insulation Resistance
0M min (DC 25V)
