IDK-1107WR User Manual 2
This specification applies to the 7” inch color TFT LCD module IDK-1107WR-
40WVA1E/IDK-1107WR-50WSA1E.
IDK-1107WR-40WVA1E/IDK-1107WR-50WSA1E is designed with wide viewing
angle; wide operating temperature and long life LED backlights are well suited to dis-
play units for Industrial Applications.
LED driving board for backlight unit is included in this panel and the structure of the
LED unit is replaceable.
IDK-1107WR-40WVA1E/IDK-1107WR-50WSA1E is built in timing controller and
LVDS interface.
The screen format is intended to support the SVGA (800(H) x 480(V)) and WSVGA
(1024(H) x 600(V)) screen and 16.2M (RGB8-bits) or 262k colors (RGB 6-bits). IDK-
1107WR-40WVA1E/ IDK-1107WR-50WSA1E is a RoHS compliant product.
1.1 Display Characteristics
1.1.1 IDK-1107WR-40WVA1E
The following table items are display characteristics under 25°C conditions.
1.1.2 IDK-1107WR-50WSA1E
Items Unit Specifications
Screen Diagonal [inch] 7.0 (177.8mm)
Active Area [mm] 152.40(H) x 91.44(V)
Pixels H x V 800x3(RGB) x 480
Pixel Pitch [mm] 0.1905 x 0.1905
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ
Typical Power Consumption [Watt] 3.7 typ.
Weight [Grams] 305 ± 10
Physical Size [mm] 170.0(W) x 111.0(H) x 7.5(D) typ.
Electrical Interface 1 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 262K(6-bit) / 16.2M(8-bit)
Temperature Range
Operating
Storage (Non-Operating)
[°C]
[°C]
-5 to +60 (panel surface temperature)
-30 to +70
RoHS Compliance RoHS Compliance
Items Unit Specifications
Screen Diagonal [inch] 7.0 (Diagonal)
Active Area [mm] 153.60(H) x 90.0(V)
Pixels H x V 1024 x 3(RGB) x 600
Pixel Pitch [mm] 0.05x 0.15
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ
Typical Power Consumption [Watt] 3.567 typ.
