IDK-1107WP User Manual 24
6.1 Touch Controller Characteristics
EETI EXC3132 is a MCU based projected capacitive touch screen controller
designed for commercial and industrial applications. EXC3132 controller supports
high voltage driving signal to achieve high SNR and better wideband interference
susceptibility.
EXC3132 provides different working frequencies to avoid narrow band interference.
With high voltage driving and different working frequencies, EXC3132 provides
excellent interference susceptibility performance. EXC3132 provides an excellent
solution for not only finger operation but also with gloves, thicker glass, etc. applica-
tions.
6.2 Specifications
Table 6.1: Specifications
Clocks
External 12M HZ crystal
Internal PLL
Internal 32 bits RTC
Clock generator for digital modules
Clock generator for analog modules
Power Management
Power supply : 3.3~5.5 VDC
Internal regulator for analog clock
Internal regulator for digital core
Idle mode
Sleep mode
ESD 4000V(HBM)
Analog Models
Up to 32 RX channels
Up to 18 TX channels
Signal generator
Communication Interface
USB 2.0 compliant full speed with LPM L1 supported
Configurable Serial Interface
-I2C : up to 400KHZ, support 3.3V
Digital Modules
Timers, Watch dog Timer
Multi-touch algorithm accelerator
Hardware scan ending
Operation Temperature -40 to 85°C
Storage Temperature -40 to 90°C
Power Consumption (mA)
Active Mode: 35mA
Idle Mode: 34mA
Sleep Mode :<33mA
(Operation Mode: Active Mode only)
Relative Humidity
Linearity (Note 1)
95% at 60°C, RH Non-condensing
Line drawing accuracy: 1pt +/- 1mm offset /10mm
Line drawing accuracy: 2pt +/- 2mm offset /10mm
Touch (point) accuracy: 1pt +/- 2.5mm
Touch (point) accuracy: 2pt +/- 5.0mm
Refer to Windows 7 Logo regulation
