IDK-1107WP User Manual 18
4.1 TFT LCD Signal (CN1): LVDS Connector
4.2 LED Backlight Unit (CN2): LED Driver Connector
Table 4.1: TFT LCD Signal (CN1): LVDS Connector
Connector Name / Description Signal Connector
Manufacturer Starconn or compatible
Mating Model Number 076B20-0048RA-G4, Starconn or equivalent
Table 4.2: Pin Assignment
Pin No. Signal Name Pin No. Signal Name
1RX3+ 2 RX3-
3NC 4 FRC
5GND 6 RXC+
7RXC- 8 GND
9 RX2+ 10 RX2-
11 GND 12 RX1+
13 RX1- 14 GND
15 RX0+ 16 RX0-
17 LR 18 UD
19 VCC_IN 20 VCC_IN
Connector Name / Designation LED Connector
Manufacturer UNE
Mating Model Number LM123S004HTF13, 4PIN, UNE
Pin # Symbol Pin Description
1 Vi Converter Input Voltage
2 ADJ Backlight Adjust
3 EN Enable pin
4 VGND Converter ground
