IDK-1107WP User Manual 2
This manual is for the 7” inch color TFT LCD module IDK-1107WP-50WVA1E which
is designed with a wide viewing angle, wide operating temperature, and long life LED
backlights which are well suited to display units for Industrial Applications. An LED
driving board for the backlight unit is included in this panel and the structure of the
LED unit is replaceable. IDK-1107WP-50WVA1E has a built in timing controller and
LVDS interface. The screen format is intended to support the SVGA (800(H) x
480(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). IDK-1107WP-
50WVA1E is a RoHS compliant product.
1.1 Display Characteristics
The following table items are display characteristics under 25°C conditions.
1.2 Optical Characteristics
Optical characteristics are measured under stable conditions at 25°C (Room Temper-
ature):
Items Unit Specifications
Screen Diagonal [inch] 7.0 (177.8mm)
Active Area [mm] 152.40(H) x 91.44(V)
Pixels H x V 800x3(RGB) x 480
Pixel Pitch [mm] 0.1905 x 0.1905
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ
Typical Power Consumption [Watt] 3.56 typ.
Weight [Grams] 160 ± 10
Physical Size [mm] 187.6(W) x 126.64(H) x 12.36(D) typ.
Electrical Interface 1 channel LVDS
Surface Treatment Clear, Haze: <2%
Support Color 262K(6-bit) / 16.2M(8-bit)
Temperature Range
Operating
Storage (Non-Operating)
[°C]
[°C]
-20 to +70 (panel surface temperature)
-40 to +80
RoHS Compliance RoHS Compliance
Item Unit Conditions Min. Typ. Max. Note
White Luminance
[cd/m2] IF= 80mA (center
point)
400 500 - 4
Uniformity % 5 Points 75% 1,5
Contrast Ratio 500 600 - 3
Response Time
[msec] Rising - 5 10
2[msec] Falling - 11 16
[msec] Rising + Falling - 16 26
Viewing Angle
[degree] Horizontal (Right) 60 70 -
6
[degree]
CR
10 (Left)
60 70 -
[degree] Vertical (Upper) 50 60 -
[degree]
CR
10 (Lower)
50 60 -
