Je bekijkt pagina 8 van 33
IDK-1105R-50VGB1 User Manual 2
This specification applies to the 5.7″ color TFT LCD module, IDK-1105R.
IDK-1105R is designed with a wide operating temperature range and long-life LED
backlights are well suited to display units for industrial applications.
An LED driving board for the backlight unit is included in this panel and the structure
of the LED unit is replaceable.
IDK-1105R has a built-in 4-wire resistive touchscreen, timing controller, and LVDS
interface.
The screen format is intended to support the VGA 640(H) x 480(V) screen and 262k
colors (RGB 6-bit). IDK-1105 is an RoHS 2.0 compliant product.
1.1 Overview
The following table shows display characteristics under conditions at 25°C.
Table 1.1: Overview
LCD Panel
Display Size 5.7", 4:3
Resolution 640 x 480
Display Mode Normally black (IPS)
Viewing Angle (U/D/L/R) 85°/85°/85°/85°
Brightness
500 cd/m
2
Backlight Life (hrs) 50,000
Contrast Ratio 1200:1
Response Time (ms) 50 ms
Colors 6-bit (262K)
Voltage 3.3 V Power
Consumption 2.1 Watts
Signal Interface 1 LVDS channel
Weight 230 g after touch
Display Size 5.7", 4:3
Dimensions (W x H x D) 127.0 x 98.43 x 9.26 mm after touch
Touch Screen
Touchscreen 4-wire resistive
Transparency 82.5 ± 2.5%
Surface Hardness 3H
Durability 1 million times
Environment
Operating Temperature -20 ~ 70°C
Storage Temperature -30 ~ 80°C
Humidity 5 ~ 90% @ Max. 40°C, non-condensing
