ICR-2041
1.10 DIN Rail Mounting
The DIN rail clip is not supplied with the router as standard accessories, but it can be ordered
by the order code BB-DIN-ICR32.
The DIN rail clip is suitable for a DIN rail according to EN 60715 standard only. The default
position of the clip is shown in Figure 8.
When mounting the DIN rail clip, tighten the screws with max. torque of 0.4 Nm.
Figure 8: Position of the DIN Rail Clip
To remove the router from the DIN rail it is necessary to lightly push down the router so
that the bottom part of the DIN rail clip hitched to the DIN rail get out of this rail and then fold
out the bottom part of the router away from the DIN rail, see Figure 9.
Figure 9: Removing Router from the DIN Rail
13
