3.
Product Specification
3.1 Overview
The FWA-6172 is a 2U rackmount network appliance powered by the 4
th
/5
th
Generation Intel® Xeon®
Scalable platform.
The 4
th
/5
th
Generation Intel® Xeon® Scalable Processors are equipped with Intel Quick Assist
Technology (QAT Gen 4), enhancing encrypted packet throughput.
The FWA-6172 platform features two integrated 1GbE wired networking ports, one dedicated IPMI
port, and supports up to eight NMC expansion slots. Storage options encompass two M.2 2280 SSDs
and two 2.5” SSDs.
For more information related to the FWA-6172, please refer to the following section:
3.2 Introduction
3.2.1 Features
o CPU: 4
th
/5
th
Generation Intel® Xeon® Scalable Processors
o Memory: 16 DDR5 memory sockets with up to 1TB capacity (RDIMM)
o NMC: Up to 8 slots, each 200GbE bandwidth
o Storage: 2 hot-swappable 2.5” SSD and 2 M.2 2280 SSD
o System Fan: 4 hot-swappable 80mm fans
o Power Supply Unit: 1200W Redundant PSU
Figure 3.2-1 System Front Panel
Figure 3.2-2 System Rear Panel
Table 3.2-1 Indications on Front and Rear Panels
A
Power Button
H
Graphic mode LCM
B
SW
-
defined Button
I
2 x hot
-
swap
2.5”
drive bays
C
1 x GbE LAN (dedicated fo
r IPMI)
J
4 x Advantech NMC slots (CPU
-
0)
D
RJ45 console port
K
4 x Advantech NMC slots (CPU
-
1
)
E
2 x GbE RJ45 ports for MGMT
L
4 x 8038 fan modules (hot
-
swap)
F
2 x USB 3.0 ports
M
1200W Redundant PSU
G
System LEDs
N
V
GA port
