3.4.1 Processor(s)
The FWA-1214 supports single Intel Atom® x7433RE or x7835RE processors. The table below gives an
overview of the processor SKUs for communication infrastructure which can be supported on the FWA-1214:
Table 3.4-2 Intel Atom® x7000 series processors supported list
CPU SKU Cores Base Frequency
Cache DDR5 TDP
x7433RE 4 1.5GHz 6MB 4800MHz 9W
x7835RE 8 1.3GHz 6MB 4800MHz 12W
3.4.2 Network Interface
In the front panel, FWA-1214 provide all the on-board LAN ports for network connection.
The FWA-1214 supports 4 x 1GbE RJ45 ports and additional 2 x 1GbE RJ45 or SFP ports (By SKU)
implemented using Intel i210 Ethernet controllers.
Figure 3.4-1 On-board Network Ports
FWA-1214 can support LTE connection by installing NMC-R0DK-00A1 and NMC-R014T-12A1 modules. NMC-
R014T-12A1 is pre-installed with LN920A LTE module and antenna kits and supports 2x SIM slots. FWA-1214
can install up to two NMC-R014T-12A1 modules.
Note! The certification of FWA-1214 does not include RF certification. According to the
regulations of the country, it may be necessary to obtain RF certification when using FWA-1214
with NMC-R014T-12A1 installed. If you need to purchase and install NMC-R014T-12A1, please
