3 FPM-800S Series User Manual
Chapter 1 General Information
1.3 LCD Specification
1.4 Connectors
The following connectors are situated on the bottom side of the FPM-800S series:
VGA Port (DB-15)
DB-15 connector can be connected to the system via the external 15-pin DB-15
connector located on the left side of the system unit.
Touchscreen Connector (USB)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the USB port of the PC. The touchscreen cable is included with all
orders.
DC 24V Power Input Connector
This connector must be connected to DC 24V power switch.
Please note before connecting the monitor and PC with a VGA cable:
1. If your PC has an OS installed, please confirm its refresh frequency is within the
acceptable range.
Specifications 15” 17"
Display Type XGA TFT LCD SXGA TFT LCD
Display Size 15" 17"
Max. Colors 16.7M Max 16.7M Max
Resolution 1024 x 768 1280 x 1024
View Angle (H/V°) 160°(V), 160°(H) 178°(V), 178°(H)
Luminance 300 cd/m2 250 cd/m2
Storage Temperature -20 ~ 60°C -20 ~ 60°C
Operating Temperature 0 ~ 50°C 0 ~ 50°C
Contrast Ratio 500:1 1000:1
Lamp Life Time (MTBF) 50,000 hrs. 50,000 hrs.
Warning! Avoid exposing FPM-800S to direct sunlight for long periods of time.
Direct sunlight falling onto an LCD screen can cause it to become very
hot and physically damage the LCD as the components are not
designed to tolerate high heat - therefore shortening the life of the LCD.
