FPM-7000T Series User Manual 2
A.1 OSD Board Overview (FPM-71x1T)
A.1.0.1 OSD Button Description
A.1.0.2 LED Functions
A.1.1 OSD Key Functions
Each selected value is stored into LCD memory after SEL signal input or time out.
The stored values are not affected if the power is turned off. But the selected value is
not available in case a selected mode is changed before time out or power is turned
off before time out. TIME OUT 5-6 seconds (Can be set in OSD Manager) The
default definition of input keys is shown as following:
Buttons Descriptions
Source Changes input video source
Menu/Sel
Activate the OSD menu
Enter /confirm the selected option
Left/Decrease
Arrow
Activate volume control.
Move the selector to the previous option
Decrease the gauge value of the selected option
Brightness can be decreased by left button.
Right/Increase
Arrow
Activate the volume control.
Move the selector to the next option
Increase the gauge value of selected option.
Brightness can be increased using the right button.
Auto/Exit
Automatically adjust the closck, phase, H-position and V-position.
Exit menu
Power Turn the monitor ON and OFF
On Green
StandBy/Off Green Blinking
No Signals Orange
