FPM-7000T Series User Manual 4
1.4 Power Consumption
Max Power consumption:
– FPM-7061T: 10 W ± 20%
– FPM-7121T: 18 W ± 20%
– FPM-7151T: 16 W ± 20%
Power input: Phoenix Jack: 24 VDC ± 20%
Safety Standards: BSMI, CE, FCC, CCC, UL
1.5 Connectors
The following connectors are situated on FPM-7000T Series:
VGA Port (DB-15)
This DB-15 connector can be connected to the system via the external 15-pin
DB-15 connector located on the left side of the system unit.
DP or HDMI port
Connected with a standard DP or HDMI connector thru I/O port of this unit. Only
supports digital signals
Touchscreen Connector (DB-9)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the RS-232 port of the PC. The touchscreen cable is included with all
orders which include the touchscreen option.
Touchscreen Connector (USB)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the USB port of the PC. The touchscreen cable is included with all
orders which include the USB touchscreen option.
Plug-In Block 3P Male (ME050-50803) DC 24 V
This block connector can be connected via the external plug-in block 3P with
flanges Female MC211-F103 connector
Note! RS-232 & USB touchscreen interface allow connection into the system
at the same time, but USB interface has higher priority. Also be noted
that when using USB touch interface and switch to RS-232 interface, it
need to restart your industrial PCs or workstation.
