3 FPM-1150G Series User Manual
Chapter 1 General Information
1.3 LCD Specification
1.4 Connectors
The following connectors are situated on the bottom side of the FPM-1150G series:
VGA Port (DB-15)
This DB-15 connector can be connected to the system via the external 15-pin
DB-15 connector located on the left side of the system unit.
Touchscreen Connector (USB)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the USB port of the PC. The touchscreen cable is included with all
orders.
DC 12 V Power Input Connector
This connector must be connected to DC 12 V power switch.
Specifications
15” LCD
(LED Backlight)
Display Type XGA TFT LCD
Display Size 15”
Max. Colors 16.7 M
Max. Resolution 1024 x 768
View Angle
(H/V°)
160°(V), 140°(H)
Luminance
300 cd/m
2
Storage
Temperature
-20 ~ 60°C
Operating
Temperature
0 ~ 50°C
Contrast Ratio 2000:1 (Typical)
Lamp Life Time
(MTBF)
70,000 hrs.
Warning! Please note before connect the monitor and PC with VGA cable:
1. If PC has installed operation system, please confirm its portrait fre-
quency is within the acceptable range.
2. If PC has installed operation system, users need to adjust the por-
trait frequency to be within the acceptable range.
