7 ADAM-3600 Series User Manual
Chapter 2 Specifications
2.2.2 Expansion Module Specifications
ADAM-3600-C2G support four slots expansion can support different type I/O mod-
ules in one integrated unit.
2.2.2.1 ADAM-3617 (4-ch AI)
2.2.2.2 ADAM-3618 (3-ch Thermocouple )
2.2.2.3 ADAM-3622 (2-ch AO
)
Channel 4, differential
Input Type Voltage, Current
Voltage/Current Range ±10V, ±2.5V, 0~20mA, 4~20 mA
Resolution 16-bit
Sampling rate 10 samples/second (total)
Input Impedance
10M
Accuracy ±0.1% or better (Full Scale)
CMR @ 50/60 Hz 120 dB
NMR @ 50/60 Hz 100 dB
Span Drift
± 25 ppm/
O
C
Zero Drift
± 3 μV/
O
C, ± 3 μA/
O
C
Isolation Voltage 2000V
DC
Burn-out detection Yes (Current-only)
Channel 3 , differential
Input Type J,K,T,E,R,S,B Type Thermocouple
Resolution 16-bit
Sampling rate 10 samples/second (total)
Input Impedance
2M
Accuracy ±0.1% or better (Full Scale)
CMR @ 50/60 Hz 90dBs
NMR @ 50/60 Hz 60dBs
Span Drift
± 25 ppm/
O
C
Zero Drift
± 3 μV/
O
C
Isolation Voltage 2000 V
DC
Burn-out detection Yes (Current-only)
Channel 2
Output Type Voltage, Current
Output Range 0 ~ 10 VDC, 0~20 mA, 4~20 mA
Resolution 12-bit
Accuary ±0.1% or better (Full Scale)
Current Load Resistor 0 ~ 500
Span Drift
± 25 ppm/
O
C
Zero Drift
± 3 μV/
O
C
Isolation Voltage 2000 V
DC
Burn-out detection Yes (Current-only)
