EPD-230/232 User Manual 14
3.2 Device LED Button Behavior
3.2.1 EPD-230, EPD-232 button behaviors:
3.2.2 EPD-230, EPD-232 LED behavior
Remote control commands from the Router.
item Status Action Result
1 SW1 (P1) no press
Press button for 0.5 sec and
release button
Refresh EPD to Page 1
2 SW2(P2) no press
Press button for 0.5 sec and
release button
Refresh EPD to Page 2
3 SW3 (P3) no press
Press button for 0.5 sec and
release button
Refresh EPD to Page 3
4
Press SW1(P1) &
SW3(P3)
Step1: Long press button (SW1 &
SW3) when LED1,LED2 and
LED3 off
Step2: LED2 flash (0.5 sec toggle
LED2)
after hold SW1& SW3 for 5 sec
Step3: LED2 on after hold SW1 &
SW3 for 10 sec
Step4: Release SW1 & SW3 keys
then LED2 off
Reset to default and reboot
Note: All images and set-
tings in the device will be
deleted.
5
If device loses con-
nection, press either
SW1\SW\SW3
Press and release button.
Leave sleep mode and try to
connect to a network .
Item Status Action Result
1 LED1 Remote Control by DeviceOn/ePaper API On/Off/Blink
2 LED2 Remote Control by DeviceOn/ePaper API On/Off /Blink
3 LED3 Remote Control by DeviceOn/ePaper API On/Off/Blink
