EPD-230/232 User Manual 2
1.1 Introduction
EPD-230, EPD-232 is an ePaper device which Supportss ultra low power 2.4GHz RF
wireless integrated with a 2.9” EPD with an ARM Cortex-M3 processor. The device is
designed for hospital, pharmacy, factory, warehouse and retail applications. With
optimization on power consumption and device management, low data rate applica-
tions can achieve years of battery life and thousand of device connections. Advant-
ech’s EPD-230, EPD-232 provides multiple interface for application control which is
highly integrated with a low power consumption system. EPD-230, EPD-232 can
auto join and bind the network with the Router (WISE-3240). Data can be quickly and
easily acquired and transformed into different formats to communicate with the Devi-
ceOn/ePaper Server.
The main features of EPD-230, EPD-232 are:
ARM Cortex-M3 Core Processor
Supports IEEE 802.15.4 / 2.4 G networks
2.9" e-Paper panel display
Low power consumption and years of battery life
Multiple I/O with 3 buttons & 3 LEDs
Supports temperature ranges: 0 ~ 50 °C
High Performance integrated system with RTOS
Supports over-the-air upgrades (OTA)
Available solution kit for various application deployments
Supports with Colors Black/White in EPD-230 or Black/White/Red in EPD-232
1.2 Specifications
Computing System
MCU TI 32-bit ARM Cortex-M3 Processor
Memory RAM 28KB
Display
Screen Size 79 x 36.7 mm
Resolution 296 x 128 pixels
Storage
Internal Flash: 128 KB
External SPI Flash: 512KB
Network
Standard IEEE 802.15.4
Frequency Band 2.4-GHz
Channels 11~26
Channel Separation 5MHz
Transmit Power -21dBm~ +5dBm
Receiver Sensitivity -100dBm
RF Data Rate 250 Kbps
Function End node
Antenna On-board Antenna
Interface
LED x3
Function Key x3
Power Battery CR2450 x4
Color
Red/Black/White
Black/White
