EPC-S101 User Manual 2
1.1 Overview
EPC-S101 is a thin design and multi-function bare-bone chassis for space-limited
solutions. EPC-S101 measures only 188 x 39 x 150 mm, less than 1U height. This
slim, fanless system provides 6 USB ports, 4 COM ports (RS-232/422/485), 2 gigabit
Ethernet ports, 1 HDMI, 1 VGA, 8-bit Digital I/O port, and audio jack w/ Mic in, line out
and line out ports ready for use. Moreover, EPC-S101 is reserved with 2.5” SATA
SSD room with SATA power, mSATA, and full-size mini-PCIe with SIM holder for mul-
tiple expansions. For mounting purposes, EPC-S101 supports wall mount, VESA
mount, and din rail mounting to cope with different application circumstances.
With condensed system size, various IO ports and flexible mounting methods, EPC-
S101 is suitable for retail, commercial kiosk and signage, environmental monitoring,
and HMI device implementation. The system is small but versatile and strong, mak-
ing it suitable for different fields of work and tasks.
1.2 Product Feature
1.2.1 Processor System
System Memory: Single Channel DDR3L-1600 2GB (Configurable up to 8GB)
Graphics: Intel SoC integrated Graphics Controller
– 3D: DX11.1, OpenGL 4.2, OpenCL 1.2
– HW Decode: HEVC (H.265)@L5, H.264@L5.2, VP8, MPEG2, MVC, VC-1,
WMV9, JPEG/MJPEG
– HW Encode: H.264@L5.1, MVC, JPEG/MJPEG
– Supports dual simultaneous display content
BIOS: AMI UEFI BIOS at 64 Mb
CPU: Intel® Celeron® N3160/N3060, Intel® Atom™ X5-E8000 SoC
CPU Intel Celeron N3160 Intel Celeron N3060 Intel Atom x5-E8000
Base Frequency 1.60 GHz 1.60 GHz 1.04 GHz
Burst Frequency 2.24 GHz 2.48 GHz 2.00 GHz
# of Cores 424
# of Threads 424
L2 Cache 2 MB 2 MB 2 MB
TDP 6 W6 W5W
CPU Intel Celeron N3160 Intel Celeron N3060 Intel Atom x5-E8000
Graphics Core Intel HD Graphics 400 Intel HD Graphics 400 Intel HD Graphics
Base Frequency 320 MHz 320 MHz 320 MHz
Burst Frequency 640 MHz 600 MHz -
Execution Units 12 12 12
