EPC-R4710 User Manual 2
1.1 Introduction
EPC-R4710 is an Arm based box computer powered by a high-performance Rock-
chip RK3399 ARM dual Cortex-A72 and quad Cortex-A53 processors. This solution
supports 4K displays via HDMI. It delivers both dual HDMI/LVDS/eDP and diverse I/
O — including GbE, 6 x serials, 6 x USB, and 5 x GPIO. EPC-R4710 also features
Mini-PCIe, M.2, and SIM card slots for integrating Wi-Fi, Bluetooth, and 3G/4G mod-
ules. It is an ideal solution for kiosk, POS, and vending machine applications.
1.2 Product Features
1.2.1 Specification
Module Name EPC-R4710
Processor
SOC Rockchip RK3399 ARM
Spec. Dual Cortex-A72 and quad Cortex-A53 1.8 GHz
Memory
Technology LPDDR4 1333MHz
Capacity Onboard 2G
Flash 16GB eMMC NAND Flas
Ethernet
Chipset RTL8211FSI
Speed 2 x 10/100/1000Mbit
Watch Dog Timer Yes
RTC Yes
I/O
GPIO 5 x GPIO via D-SUB 9 (3.3V TTL level)
Serial Port
1 x RS232/debug
3 x RS232 w/2wire
2 x RS232/485 w/4wier
USB host/OTG 5 x USB Type A, 1 x USB OTG
SPI 1 x SPI by pin header
I2C 1 x I2C by pin header
Expansion
Mini-PCIE 1 x Full size mini PCIe slot (USB signal only)
M.2 1 x M.2 2230 Key E slot, w/SIDO*UART*PCIe*USB
SIM slot 1 x SIM slot
SD socket 1 x Micro SD slot
LED system indicators
1 x Green LED for system power
1 x Orange LED for WLAN
Button 1 x Power button, 1 x Reset button
Power
Power supply 12V
Power Type DC-in
Consumption Boost 15W@12V
SW OS Android/Debian
Mounting Wall mount
