3 EPC-R3710 User Manual
Chapter 1 General Introduction
1.2 Product Features
1.2.1 Specifications
Model
EPC-R3710NO-
XAA100
EPC-R3710NO-
XAA120
EPC-R3710NO-
XAA140
EPC-R3710NO-
XAA160
Processor
System
CPU Rockchip RK3399 ARM dual Cortex-A72 and quad Cortex-A53 1.8 GHz
Memory
Technology LPDDR4
Capacity 2 GB On-board
Flash 16GB of eMMC NAND Flash for OS and Advantech's boot loader
Graphics
HDMI 1 HDMI 2.0, 1920 x 1080 at 60Hz
Graphics
Engine
OpenGL ES 1.1/2.0/3.1, OpenCL 1.1, DirectX 11
H/W Video
Codec
Decoder: MPEG-1, MPEG-2, MPEG-4, H.263, H.264, AVS, VC-1, VP8, MVC, HEVC/
H.265 decoder, 4k@60FPS
Encoder: H.264 (BP@level4.0, MP, HP@level4.0), MVC and VP8
Ethernet
Chipset RTL8211FSI
Speed 2 10/100/1000 Mbps
Watchdog
Timer
Watchdog
Timer
Yes
Front I/O
USB 1 x USB 3.0 Type A, 1 x USB 2.0 Type A
GbE 2 x RJ45 for GbE
Rear I/O
1 x RS-485, 1 x 2
wires RS-232
4 x DIs, 4 x DOs
2 x 2 wires RS-232
1 x GbE, 2 x USB
2.0
2 x 2 wires RS-232 4 X GbE (Hub)
Expansion
Full-Size
Mini PCIe
1 Full Size Mini PCIe Slot (with PCIE/USB)
M.2 Micro -
SD Socket 1 Micro SD Socket
SIM 1 Nano SIM Slot
Antenna
Holes
3
Power
Power Supply
Voltage
+12V
Power Type Lockable DC-Jack
Power
Consumption
11.5W (burning)
Environment
Operating
Temperature
0 ~ 50 °C/-20 ~ 70 °C (32 ~ 122/-4 ~ 158 °F)
Operating
Humidity
5 ~ 95% relative humidity, non-condensing
Mechanical
Dimensions 174 x 108 x 25 mm (6.85 x 4.25 x.98 in)
Mounting Wall mount/Din Rail
Weight TBD
Operating
System
Linux Debian
Android Android
Certifications CCC/CE/FCC/BSMI Class B
