PRODUCT OVERVIEW
8
1.3. Hardware Views
1.3.1 Front View
The following view applies to EKI-5525, EKI-5525I, EKI-5725 and EKI-5725I.
Figure 1-1. Front View
Table 1-4. Front View
No. Item Description
1 System LED panel See “System LED Panel” on page 22 for further details.
2 ETH port EKI-5525/EKI-5525I: Four 10/100BaseT(X) ports.
EKI-5725/EKI-5725I: Four 10/100/1000BaseT(X) ports.
Port numbers in black are designated for port based Quality of Ser-
vice (QoS) functionality.
3 LNK/ACT LED Link activity LED.
3
4
5
P2
P1
P-Fail
Loop
1
2
EKI-5725
1
2
5
3
4
