EKI-5000 Series User Manual 6
1.3 Hardware Views
1.3.1 Front View
1.3.1.1 8 x ETH Port Series
The following view applies to EKI-5528-EI, EKI-5528-MB, EKI-5528-PN, EKI-5528I-
EI, EKI-5528I-MB, EKI-5528I-PN, EKI-5528-PNMA, and EKI-5728I-MB.
Figure 1.1 Front View
No. Item Description
1.
System LED panel See “System LED Panel” on page 10 for further details.
2.
ETH port 8 x 10/100BaseT(X) ports.
Port numbers in black are designated for port based Quality of
Service (QoS) functionality.
3.
LNK/ACT LED Link activity LED.
4.
Speed LED
Gigabit Ethernet:
– Green: 100M
– Off: 10M
Fast Ethernet:
– Amber: 100M
– Off: 10M
P2
P1
P-Fail
Loop
8
7
6
5
3
4
1
2
EKI-5528-EI
1
2
3
4
