3 ECU-579 User Manual
Chapter 1 Overview
1.2 Hardware Specifications
1.2.1 General
Certifications: CE, FCC Class A, IEC 61850-3, IEEE 1613, CB/UL
Dimensions (W x D x H): 440 x 460 x 88 mm
Enclosure: SECC & Aluminum
Mounting: 2U 19” Rackmount
Power Requirements:
– Redundant Power Supply, 800W
– ECU-579-SSDA: 100 ~ 240 V
AC
, 50-60Hz, 10-5A
– ECU-579-SSDB:
100 ~ 240 V
AC
, 50-60Hz, 10-5A
100 ~ 240 V
DC
, 11.5-4A
– ECU-579-SSDC: 48 V
DC
, 30-15A
Weight: 11 kg
OS Support: Windows 10, Windows Server 2012, 2016, 2019, 2022 and Linux
Hypervisior Support: VMware ESXi 8.0 U3, RHEL 8.2
1.2.2 System Hardware
CPU: 1st & 2nd Generation Intel
®
Xeon
®
Scalable Processors to be selected
and assembled
Memory: DDR4 RDIMM/LRDIMM-ECC 2400/2666/2933 MHz (4 GB, 8 GB, 16
GB, 32 GB, 64 GB) x 12 slots up to 768 GB
Indicators: LEDs for Power. HDD, programmable LED, LAN (LINK, ACT),
expansion cards
Storage: hot-swappable 4 x 2.5" SATA SSD (RAID0, RAID1, RAID5, RAID10),
1 x M.2 SATA/NVMe
Expansion Interface:
– 1 X Proprietary PCI/PCIe (ECU-P)
– 1 X PCIe p13-x4 slot Gen. 3
– 1 X PCIe p13-x8 slot Gen. 3
– 2 X PCIe x16 slots Gen. 3
– 1 X Mini PCIe (PCIe p13-x1 Gen. 1 + USB 2.0)
Table 1.1: Power Consumption (Watts)
System Configuration Idle Mode Max. Condition
ECU-579 Base System
200 300
24 Cores CPU, TDP 150W (Xeon® 8160T)
8 x 16 GB DDR4 RDIMM
4 x 64 GB SATA III 2.5" SSD
