ECU-4784 User Manual 4
1.2 Hardware Specifications
Model
ECU-4784-C3xxxx
ECU-4784-E3xxxx
ECU-4784-E4xxxx
ECU-4784-E5xxxx ECU-4784-G5xxxx
General
Certification IEC 61850-3, IEEE 1613, CE, FCC class A, UL, CCC, CB, LVD
Dimensions
(W x D x H)
2U (440 x 280 x 88 mm / 17.3" x 8.6" x 3.4")
Enclosure SECC & Aluminum
Mounting 2U Rack mount
Input
100 ~ 240 V
AC
or 100 ~ 240 V
DC
; 48V
DC
optional with selectable power module
Power Type ATX, AT
Weight 6.0 kg
System
Design
Fanless design
OS Support Windows 10, Windows Server 2016/2019, Linux
System Hardware
SOM SOM-6897 SOM-5897 SOM-5899
CPU
3955U, i5-6300U,
i7-6600U
E3-1505L v5 E-2276ML
Memory DDR3L DDR4 DDR4
Display 1 x DVI-D, 1 x DVI-I 1 x DVI-D, 1 x VGA 1 x DVI-D, 1 x DVI-I
Indicators LEDs for Power, SSD, Programmable LED, LAN (Active, Status) and Serial (Tx, Rx)
Storage
3 x 2.5" SATA SSD (RAID
0,1,5); 1 x M.2 PCIe
2 x 2.5" SATA SSD (RAID
0,1); 1 x CFast
3 x 2.5" SATA SSD (RAID
0,1,5); 1 x M.2 PCIe
Watchdog
Timer
Programmable 256-level time intervals, from 1 to 255 seconds for each tier
I/O Interface
Serial Ports
2 x DB-9 RS-232 (9-wired), 8 x terminal block (5-wired), RS-422/485
(Automatic RS-485 data flow control) 2,000 V
DC
isolation
Serial Port
Speed
(COM1 ~ COM2) RS-232: 50 ~ 115200 bps
(COM3 ~ COM10) RS-422/485: 50 ~ 921600 bps
LAN
1 x 10/100/1000 Base T RJ45 ports (Intel i219LM GbE Controller, AMT, Teaming
Function, PXE)
7 x 10/100/1000 Base T RJ45 ports (Intel i210 GbE Controller, Teaming Function,
PXE)
USB
4 x USB, UHCI, rev 2.0 compliant (3 x rear,1 x internal)
2 x USB, UHCI, rev 3.0 compliant (2 x front)
Expansion 2 x Domain I/O Expansions (Each Slot Supports up to 1 PCIe or 2 PCI devices)
Relay Output
Form C, Contact 5 A @ 125 V
AC
/5 A @ 30 V
DC
(For IEC-61010-2-201)
Programmable
LED
8-ch programmable LED indicator
